MSI PRO FORGE M051R Compact Mini Tower

The PRO FORGE M051R is a compact mini tower case designed for modern business users, offering flexible configurations for a clean and efficient setup, whether for work or entertainment.

PRO FORGE M051R

• ARGB Fan：Built-in ARGB fans with striking lighting and vivid lighting effects.
• Pre-installed Fan Included：Comes with four pre-installed fans, three in the front and one at the rear, for balanced airflow and reliable cooling.
• Dust Filter：Top and bottom dust filters improve airflow and protect internal components from dust buildup.
• EZ Connect：Connect fans in series to share a single set of PWM and RGB ports on the motherboard for simplifying PC installation and cable management.

Product Name

PRO FORGE M051R

Case Form Factor

Mini Tower

Motherboard Form Factor Support

Micro-ATX, Mini-ITX

I/O Ports

1 x Power Button
1 x Reset Button
1 x Audio Out
1 x Mic In
2 x USB (Type-A)
1 x USB 5Gbps (Type-A)

Drive Mount Support

2 x 2.5"
2 x 2.5" / 3.5" Combo Tray

Expansion Slots

4

Maximum GPU Length

300 mm / 11.81 inches

Maximum CPU Cooler Height

160 mm / 6.30 inches

Power Supply Support

Micro-ATX

Maximum PSU Length

170 mm / 6.69 inches

Fan Size Support

Front: 3 x 120 mm / 2 x 140 mm
Rear: 1 x 120 mm
Top: 2 x 120 mm
Side: N/A
Bottom: N/A

Pre-installed Fan Type

Front: 3 x 120 mm ARGB Fan
Rear: 1 x 120 mm ARGB Fan

Radiator Size Support

Front: N/A
Rear: 120 mm
Top: 120 / 240 mm
Side: N/A
Bottom: N/A

Dimensions (DxWxH)

388 x 200 x 423 mm / 15.28 x 7.87 x 16.65 inches

Net Weight

4.40 kg / 9.70 lbs

Gross Weight

5.23 kg / 11.53 lbs

Connections
